The MONICON L is a versatile, compact studio monitor controller for professional project studios and ambitious home set-ups. It features three inputs for different signal sources: balanced via XLR/TRS combo sockets as well as AUX and Bluetooth for mobile or digital devices. The inputs and outputs can be switched on/off via dedicated buttons with LED status display.

Two stereo outputs and an additional mono output allow flexible control of the speakers, for example, for main monitors, nearfield systems, or subwoofers. The large analogue volume control allows precise control of the output level.

Functions such as “Mono,” “Dim,” and “Mute” support practical monitoring conditions and facilitate quick adjustments in everyday studio life.

With its own volume control and PFL function, a separate headphone output allows isolated pre-listening to input signals without affecting the main mix.

The integrated power supply provides power to the Bluetooth, the headphone amplifier, and output three. The signal path itself stays entirely analogue, which makes latency-free and pristine audio playback possible. MONICON L stands for reliable signal management, transparent sound control, and intuitive operation.

Inputs: 3× Stereo (balanced XLR/TRS Combo, AUX and Bluetooth)
Outputs: 2× Stereo, 1× Mono outputs (balanced XLR)
Latency-free analogue audio signal path
Supports both passive and active operation
Large precision volume control
AUX/Bluetooth input with dedicated volume control
Stereo Phones output with independent volume control
Input and output source selectors with Status LEDs
Dedicated switches for MONO, DIM, MUTE and PFL source
Robust and ergonomic desktop housing
Engineered in Germany

General

Type	Passive
Material	Aluminium
Material	Steel sheet
Frequency response (±0.2 dB, rel. Avg)	20 - 20,000 Hz
Colour	Black

Bluetooth®

Bluetooth® version	Bluetooth® 5.3
Features	Audio Streaming (A2DP)
Supported audio codecs	SBC

Inputs

Input signal type	Balanced & Unbalanced (parallel)
Number of balanced line inputs	2
Balanced Line-In connector type	XLR combo socket
Number of unbalanced line inputs	2
Unbalanced Line-In connector type	2 x RCA female (Stereo)
Unbalanced Line-In connector type	3.5 mm Jack TRS female

Line input performance

Nom. input clipping, balanced (< 1% THD, 1 kHz, unity)	20 dBu
Nom. input clipping, unbalanced (< 1% THD, 1 kHz, unity)	15 dBu
Input impedance (balanced)	20 kΩ
Input impedance (unbalanced)	10 kΩ
THD+N	≤ 0.001 % (+4 dBu)
Min. CMRR (0 dB below clip, 1 kHz, unity)	55 dB
Min. SNR (< 1% THD, 1 kHz, unity, A-weighted)	112 dB

Outputs

Output signal type	Balanced
Output signal type	Headphone
Number of balanced line outputs	5
Balanced line outputs connector type	XLR 3-pole male
Number of Headphone outs	1
Headphone out connector type	6.3 mm Jack TRS female
Min. headphone impedance	10 Ω
Max. headphone out power	100 mW
