The MAILA COL full-range column module makes MAILA truly versatile. With its 4x 6.5'' woofers, the elegant column element not only provides an extended low-mid range, but also includes a 4-channel DSP amplifier with 2.5 kW total power, which drives both the column itself and the MAILA SAT satellites.
In this way, MAILA sets with column module can not only be used as a ground stack variant, but also as a flown array consisting of MAILA COL and up to eight MAILA SAT - especially useful for festivals and fixed installations. In addition, as with a classic line array, users can select different subwoofer arrangements and adapt them to the sound reinforcement requirements on site.
On the ground, the use of MAILA COL provides a further advantage: the interconnected column module allows ground stack sound setups that are significantly higher (up to 3.4 metres) than conventional systems and, with its greater throw, also enables uniform sound coverage in the far field.
With LogoLink®, LD Systems has added another innovation to MAILA. Via the free MAILA app (iPadOS), every MAILA system can be quickly, easily and precisely adjusted and wirelessly supplied with software updates. Once connected, the app automatically recognises the existing MAILA components and enables the system to be set up quickly and easily - including calculation of the SAT angles - in the run-up to an event. The highlight: the wireless antennas are invisibly integrated into the LD logo of the MAILA COL.
- Powered column module with integrated loudspeakers and DSP power amplifier
- 4x 6.5'' woofers for extended low-mid headroom
- 4-channel DSP amplifier with SysCore® DSP and 2.5 kW total output power
- Frequency range: 105 - 500 Hz
- Flexible use in ground stack and flown setups
- SmartLink+® enables cable-free connection of column module and satellites (powering up to eight MAILA SAT)
- LogoLink®: Wireless antennas integrated in the LD logo for wireless app connection
- DSP configuration directly on the device or via the free MAILA app (iPadOS)
| Product type | MAILA Column |
| Type | Powered |
| Low/mid Woofer dimensions | 4 x 6.5 " |
| Woofer dimensions (mm) | 16.51 mm |
| Woofer magnet | Neodymium |
| Woofer brand | Custom-made |
| Woofer voice coil | 2 " |
| Woofer voice coil (mm) | 50 mm |
| Amplifier | Class D |
| System Power (RMS) | 2500 W |
| Frequency response (-6dB) | 105 Hz - 500 Hz |
| Max. SPL Peak (Pink noise) | 130 dB (fullspace @1m, Crest factor 4) |
| Max. SPL Peak (Sine burst) | 125.4 dB (fullspace @1m, 10% THD) |
| Max. SPL Average (Sine burst) | 122 dB (100 Hz - 2 kHz, fullspace @1m, 10% THD) |
| Protection circuits | limiter |
| Protection circuits | over-current |
| Protection circuits | thermal overload |
| Input impedance | 20000 Ohm(s) |
| Controls | Rotary/push encoder |
| Indicators | Indication LED |
| Indicators | LC display |
| Indicators | Limit |
| Indicators | Power |
| Indicators | Protect |
| Indicators | Signal |
| Line inputs | 1 |
| Line input connectors | XLR |
| Line outputs | 1 |
| Line output connectors | XLR |
| Speaker output connections | SmartLink+® |
| Wireless Connectivity | LogoLink® for App Control |
| Power supply | SMPS |
| Power consumption (max.) | 800 W |
| Operating voltage | 100 V AC - 240 V AC, 50 - 60 Hz |
| Operating Temperature | 0 - 40 °C |
| Relative Humidity | < 80 %, not condensing |
| Cabinet material | Die-cast aluminium |
| Cabinet surface | Powder-coated |
| Cabinet construction | Bass Reflex |
| Mounting | 3 x M10 |
| Mounting | 4 x Pin |
| Mounting | EasyMount+® |
| Handles | 2 |
| Width | 205 mm |
| Height | 1028 mm |
| Depth | 354 mm |
| Weight | 36.195 kg |
DSP characteristics
| Bit depth AD/DA converter | 24 bit |
| Sampling frequency | 48 kHz |
