| Product type |
Headphone Amp: |
| Inputs |
2 |
| Inputs |
AUX In (Stereo) |
| Input connectors |
3.5 mm stereo jack (AUX In) |
| Input connectors |
XLR-F (L + R Input, balanced) |
| Input impedance |
10000 (3.5 mm jack) Ohm(s) |
| Input impedance |
6000 (XLR In) Ohm(s) |
| Input sensitivity |
-6 (3.5 mm jack) dBV, 3 (XLR In) dBu |
| Max. input level |
7 (3.5 mm jack) dBV, 16 (XLR In) dBu |
| Protection circuits |
Audio Limiter |
| Protection circuits |
Max. Input leveling |
| Protection circuits |
Power OFF - Mute relay |
| Headphones ouputs |
1 |
| Headphones outputs |
3.5 mm TRS |
| Power Output (1% THD @ 33 Ohm Load) |
2 x 1,65 Vrms |
| Minimum connected impedance |
16 (per channel) Ohm(s) |
| Frequency response |
20 - 40000 |
| Total Harmonic Distortion (THD) |
0.04% |
| Controls |
Balance L/R |
| Controls |
Power / Volume |
| Controls |
Stereo/Mono (Focus) switch |
| Indicators |
Battery (low battery: red) |
| Indicators |
Peak (Amber) |
| Indicators |
Power LED (Power ON: green) |
| Indicators |
Signal (green) |
| Power supply |
9 V block |
| Power supply |
9 V DC power supply |
| Operating voltage |
9 V DC |
| Max. Current |
Nom. 0.07 A / Max. 0.15 |
| Cabinet material |
Plastic |
| Cabinet surface |
Soft-touch |
| Cabinet colour |
Black |
| Width |
80 mm |
| Height |
42.5 mm |
| Depth |
133 mm |
| Weight |
0.155 kg |
| Accessories (included) |
Belt clip |
